Calculation Chart

Formula of Weight:

Weight of Stainless Steel Pipes & Tubes

OD (mm)-W.T. (mm) x W.T. (mm) x 0.02466 = Kg.per Mtr.

Sheet Width Required for rolled and welded pipes

O.D. (mm) - THK (mm) x 3.14 = Sheet Width

Weight of Stainless Steel Sheets

Length (mtr.) x Wdth (mtr.) x Thk (mm) x 8 = Kg Per Sheet

Weight of Stainless Steel Circle & Blanks

OD(mm) x OD (mm) x Thk (mm) / 160 / 1000 = Kg Per Pcs.

Weight of Stainless Steel Rounds

Dia. (mm) x dia.(mm) x 0.00623 = PerMtr.

Weight of Stainless Steel Hexagonal Rods

Dia. (mm) x Dia. (mm) x 0.00679=Per Mtr.

Weight of stainless Steel Square Bars

Dia. (mm) x Dia. (mm) x 0.00787=Per Mtr.

Weight of Carbon Steel Sheets & Plates

Length (mtr.) x Wdth (mtr.) x Thk (mm) x 7.85 = Kg Per Sheet

Weight of Copper Pipes

OD (mm) - W.T. (mm) x W.T.(mm) x 0.0256 = Kg.per Mtr.

Weight of Lead Pipes(appro.)

OD (mm) - W.T. (mm) x W.T. (mm) x 0.0345 = per Mtr.

Weight of Lead Sheets (Approx)

Length (mtr.) x Width (mtr.) x Thk (mm) x 11.2 = Kg Per Sheet

Weight of Alluminium Pipes (Approx)

OD (mm) - W.T. (mm) x W.T. (mm) x 0.0082 = Kg per Mtr.

Weight of Alluminium Sheets (Approx)

Length (mtr.) x Width (mtr.) x Thk (mm) x 2.66 = Kg Per Sheet

Tensile Strength Conversion Table:

Kg/mm2 x 9.81 = N/mm2=MPa
PSi x 0.0007 = Kg/mm2
KSi x 1000 = PSi
Kg/mm2 x 1.422 = KSi
